96 Appendix A
pnic loadeproms
Load the PCI-X and front-end EEPROMs.
Syntax
pnic loadeproms [number]
Parameters
Command
History
Usage
Information
Use this command to upgrade PCI-X and front-end EEPROMs to new revisions. Reboot the
chassis after executing this command; only then does new firmware take effect.
pnic loadparams (deprecated)
Upload the runtime configuration parameters contained in the file /usr/local/pnic/0/pnic.conf.
Syntax
pnic loadparams [number]
Parameters
Command
History
number Enter the number of the network interface card.
Range: 0-5
Default: 0
Version 2.0.0.1 Introduced
Note: This process takes up to 30 minutes.
number
Enter the number of the network interface card.
Range: 0-5
Default: 0
Version 2.0.0.1 Introduced
