P-Series Installation and Operation Guide, version 2.3.1.2 91
Example Figure 55
[root@localhost SW]# pnic gui
CPU(s): 0.0% user, 0.0% system, 0.0% nice, 100.0% idle
Dev: 8002 - Type: PNIC-0 - FirmwareID: 64 - Ver:2.6 - DefaultDrop: disabled
pnic0 UP Capture=on FlowTimeout=16 Packets/flow=0 Truncation=0 Irq period=1ms
HW Interfaces CH0 Top Rate/s CH1 Top Rate/s
Total Packets 0 0 0 0
TCP Packets 0 0 0 0
UDP Packets 0 0 0 0
ICMP Packets 0 0 0 0
Other Packets 0 0 0 0
Capture Packets 0 0 0 0
Total Flows 0 0 0 0
Delayed Pkts 0 0 0 0
Stateful Pkts 0 0 0 0
Blocked Packets 0 0 0 0
OS Interface pnic0:0 Rate/s pnic0:1 Rate/s
Rx (Packets) 0 0 0 0
Rx (Bytes) 0 0 0 0
Rx (Bits) 0 0 0 0
Errors 0 0 0 0
Truncated (Pkts) 0 0 0 0
Delayed (Pkts) 0 0 0 0
h=help z=stop m=manage_rules c=truncation t=timeout f=packets/flow x=DMA
Available commands are:
a: IRQ period (ms).(Range 0-80) 0: no throttling; 80: maximum throttling.
c: Number of bytes to capture after a match. 0 means entire packet.
d: Bring the OS network interface down and disable matching.
f: Maximum number of packets captured for each flow.
h: Display this help page.
i: Number of seconds for the refresh interval.
m: Manage the dynamic rules, set the capture/forwarding policies and
select and load the firmware.
p: Toggle the display of OS stats for separate channels and combined channel.
q: Quit the program.
r: Reset all the OS counters.
s: Start or restart the PNIC drivers and reload the firmware.
t: Number of seconds after which a flow is considered expired.
u: Bring the OS network interface up and enable matching.
x: Toggle packet capture on or off.
z: Unload the PNIC drivers and disable the PNIC.
Press any key to continue
Legend:
Total packets: Number of packets received by the PNIC ports
Blocked: Packets blocked by the PNIC
TCP/UDP/ICMP: Packet types received by the active port
Other: Packet types received by the active port (not TCP/UDP/ICMP)
Total Captured: Packets matched and captured by some PNIC policy
Total Flows: Number of flows recognized by PNIC policies
Delayed: Stored packets that may become captured later
Stateful Captured: packets matched by a stateful policy
Rx Packets/Bytes/Bits: Captured data received by the OS
Errors: Anomalous rx conditions
Truncated: Truncated packets received by OS (may be because of high load)
Delayed: Captured packets that have been delayed because of stateful rule
Press any key to continue
[root@localhost SW]#
pnic gui Command Example
