P-Series Installation and Operation Guide, version 2.3.1.2 23
Capturing to a Host CPU
Captured traffic can be sent to a host CPU through a libpcap library interface, where it can be made
available to applications for analysis. A typical implementation provides IDS/Snort acceleration because
of the hardware assist.
Figure 10 Capturing Matched Traffic via the libpcap Interface
SW
HW
libpcap
tcpdump Snort Custom app
M 1 P1 P0 M0
Traffic to
monitor
PB-10GE-2P
fn90035mp
Matched Traffic
Use the P-Series in an integrated security monitoring solution through the management port. The P-Series
comes with support for Sguil NSM (see
Network Security Monitoring on page 43 ).
Figure 11 Creating a Network Monitoring Solution with the P-Series
SW
HW
libpcap
Custom app
M1 P1 P0 M0
Matched Traffic
Traffic to
monitor
Mgmt
Port
Custom
security
monitoring
application
PB-10GE-2P
fn90036mp
