P-Series Installation and Operation Guide, version 2.3.1.2 43
A key aspect of network security deployment is the ability to monitor the network for security events,
analyze them, and perform counter measures. To that end, the P-Series supports Sguil, an open source
network security monitoring and reporting system that provides the ability to:
• collect, monitor, and correlate security events/alerts in the network
• analyze security events based on context
• categorize and escalate events for intrusion response decisions
The Sguil solution consists of the following components ( Figure 27 ):
• Sensors—Sensors are the systems actually monitoring network traffic and collecting data. Sensors
perform packet captures of network traffic in addition to running Snort in alert mode.
• Database—The database holds the alert and session data that the sensors collect.
• Client—The client is the interface to the Sguil server.
• Server—The Sguil server maintains connections to the sensors, clients, and database.
Figure 27
Sguil Server
Sguil Client
Security Alert Information
P-Series Sensors
fn90025mp
Sguil Architecture
Chapter 6 Network Security Monitoring
