10
Installation
System Specifications
The specifications in
apply to the P-Series P10 appliance, Force10 catalog number
PB-10GE-2P.
Physical Connections
(Power Button)
This button turns the appliance on and off. Press and hold the button to turn off the
appliance.
(Laser Warning)
This label in the bottom right corner of the appliance indicates that the appliance is a
Class 1 laser product that emits invisible laser radiation. This product complies with
CDRH, 21 CFR 1040.
Table 1 System Specifications
Power
AC Power Supply Power Consumption: 400W maximum, 260W nominal
Current: 3.6 A @ 120V, 2.0 A @ 240V
Voltage: 100-240V, 47-63Hz, 8A maximum input current
Heat Dissipation: 1360 BTU/hr maximum, 888 BTU/hr nominal
Battery
3V CR2032 coin cell
Physical
Dimensions
Height: 1.75 in
Width: 17.6 in
Depth: 15.5 in (1RU half depth)
Weight
20 lbs (9.07 kg)
Environmental Temperature
Operating: 41° to 104°F (5° to 40°C)
Storage: -40° to 149°F (-40° to 65°C)
Relative humidity: 20-80% (non-condensing)
Altitude
Operating:-50 to 10,000 ft (-16 to 3048 m)
Storage: -50 to 35,000 ft (-16 to 10,600 m)
Note: Connections to the sensing, mirroring, and management ports require straight-through CAT5 cables.
Warning: Do not hot-swap XFPs. If they are accidentally removed, turn off the appliance, replace the
XFPs, and then turn the appliance back on.
Label
Description
FN00048A
