P-Series Installation and Operation Guide, version 2.3.1.2 29
To modify dynamic rules:
Figure 15 Editing Dynamic Rules in vi
fn90000012
pnic
Managing Capture/Forward Policies with the GUI
Upon compiling static and dynamic rules, default capture/forward policies are assigned to each rule.
To change capture/forward policies:
Step Task
1
Enter the m command from the GUI command line (see “GUI Commands” on page 26 ) to access the
main rule management GUI (see Figure 14 ).
2 Select
Edit Rules to invoke the vi editor (see
Figure 15 ).
3 Add, delete, alter, or uncomment rules using vi commands (see Appendix D , on page 125 ).
4 You are prompted to confirm your changes upon exiting the editor.
Step Task
1
Enter the
m command from the GUI command line (see
“GUI Commands” on page 26) to access the rule
management GUI (see Figure 14 ).
2 Select Manage Rules to access the policy management menu (see Figure 16 ).
3 Use the arrow keys to highlight a rule and the
Select option, and press the Enter key.
4 Select alert, permit, divert or deny, based on the descriptions in Table 5 (also see Figure 17 ).
5 Exit the menu by selecting
Done, and repeat Steps 3 through 5 for other rules, if desired.
6 Select Done; you are prompted to confirm your changes.
