V7865 Product Manual

Advanced BIOS Setup

The Advanced BIOS Setup menu allows the user to configure some CPU settings, the
IDE bus, SCSI devices, other external devices and internal drives.

Select the Advanced tab from the ezPORT setup screen to enter the Advanced BIOS
Setup screen. You can select the items in the left frame of the screen, such as SuperIO
Configuration, to go to the sub menu for that item. You can display an Advanced
BIOS Setup option by highlighting it using the keys. A sample of the
Advanced BIOS Setup screen is shown below; options in your system may be
different from those shown.

NOTE:

Changes in this screen can cause the system to malfunction. If problems are

noted after changes have been made, reboot the system and access the BIOS. From the
Exit menu select ‘

Load Failsafe Defaults

’ and reboot the system. If the system failure

prevents access to the BIOS screens, refer to Chapter One for instructions on clearing
the CMOS.

NOTE:

Options shown may not be available on your system.

BIOS SETUP UTILITY

Main

Advanced

PCIPnP

Boot

Security

Chipset

Exit

Advanced Settings

Configure CPU.

←→

Select Screen

↑↓

Select Item

Enter Go to Sub Screen
F1

General Help

F10

Save and Exit

ESC

Exit

WARNING: Setting wrong values in below sections
may cause system to malfunction.

CPU Configuration
IDE Configuration
Floppy Configuration
SuperIO Configuration
ACPI Configuration
APM Configuration
Event Log Configuration
MPS Configuration
PCI Express Configuration
Smbios Configuration
Remote Access Configuration
USB Configuration
