Organization of the Manual
17
Organization of the Manual
This manual is composed of the following chapters and appendices:
Chapter 1 - Installation and Setup describes unpacking, inspection, hardware jumper
settings, connector definitions, installation, system setup and operation of the V7865.
Chapter 2 - Standard Features describes the unit design in terms of the standard PC
memory and I/O maps, along with the standard interrupt architecture.
Chapter 3 - Embedded PC/RTOS Features describes the unit features that are beyond
standard functions.
Chapter 4 - Maintenance provides information relative to the care and maintenance of
the unit.
Appendix A - Connector Pinouts illustrates and defines the connectors included in the
unit’s I/O ports.
Appendix B - AMI BIOS describes the menus and options associated with the
American Megatrends, Inc . (system) BIOS.
Appendix C - Remote Booting describes the menus and options associated with the
Intel Boot Agent.
