Page 83
83
Keyboard and Mouse Connector and Pinout (J36)
A
Figure A-9 Mouse/Keyboard Y Splitter Cable
Table A-3 Keyboard/Mouse Y Splitter Cable
Keyboard
Mouse
Pin
Dir
Function
Pin
Dir
Function
1
In/Out
Keyboard Data
1
In/Out
Mouse Data
2
Unused
2
Unused
3
Ground
3
Ground
4
+5 V
4
+5 V
5
Out
Keyboard Clock
5
Out
Mouse Clock
6
Unused
6
Unused
Shield
Chassis Ground
Shield
Chassis Ground
Mouse/Keyboard
Port Connector
(Male)
Keyboard
Connector
(Female)
Mouse
Connector
(Female)
Pin 6
Pin 6
Pin 5
Pin 5
Pin 6
Pin 5
Ke
yboar
d
Pin 2
Pin 1
Pin 1
Pin 2
Pin 2
Pin 1
Pin 3
Pin 4
Pin 4
Pin 3
Pin 3
Pin 4
