FUJITSU Image Scanner fi-6130 - Manual (Page 190)

8.1 Scanner Settings
Selecting each item displays detailed settings (parameters) in the right part of the dialog box.
Item Explanation Selectable parameter Default
Multifeed Select the method to detect
Multifeed. (Check either of
overlapping or document
length, or both of document
length and overlapping)
None/Check Overlapping [Ultrasonic]/
Check Length/Check Overlapping and
Length.
Selectable length (to be detected as
length difference): 10, 15 or 20 mm
Check
overlapping
Page Edge Filler
Fill the end sections of a
specified-mm-wide with
white or black on the
scanned image.
When the backing
(background) color is white,
the end sections are filed
with white; and when the
background color is black,
filled with black.
ADF:
Top/left/right: 0-15 mm
Bottom: -7 to 7 mm (can be set in
increments of 1 mm)
FB:
Top/bottom/left/right:0-15 mm
(A: Image areaB: Filled area
A+B: Area to be output)
Top/Bottom/
Left/Right:
0 mm
Dropout color Drop out a preselected color
for the scanned image.
(Binary black & white/
grayscale mode only)
Red/Green/Blue/None Green
Pre-pick To give a higher priority to
processing speed, select
[Yes], if not, select [No].
Yes/No Yes
