FUJITSU Image Scanner fi-6130 User Manual
Page 119
3.17 Scanning Using Barcodes
1. Create a new batch profile on ScandAll PRO, and open the [Profile Editor] window.
For how to create a profile, see "
"
2. Click on the [Document separator] tab.
3. Mark the [Use Barcode-Based Job Separation Sheet] checkbox.
HINT
●
To suppress scanning the image of the sheet on which barcodes are printed, check
the [Remove separation sheet] checkbox.
●
In duplex scan mode, you can disable scanning the rear side of the barcode-printed
sheets by selecting the [Remove the next page of a separation sheet] checkbox.
4. Click the [Setup] button.
The [Barcode Setting] dialog box appears.
