Fortress Bridge: Configuration
29
Enabled
on the
LAN
SETTINGS
screen. If you disable STP on a
non-root Bridge, the
Multicast
field for the radio with a
Radio
Mode
setting of
Bridge
and a
Bridge Mode
setting of
Non-Root
will be configurable. Refer to Section 3.2.1 for more information
on STP.
3.3.2.7
Received Signal Strength Indicator
NOTE:
Because ra-
dios in
AP
Radio
Mode
or in
Root
Bridge
Mode
accept multiple, si-
multaneously connec-
tions, the
LED RSSI
Monitor
is not used to set
up radios configured in
this way (although it re-
mains available).
In outdoor, point-to-point/multipoint installations, the
LED RSSI
Monitor
allows you to make the first adjustments to the
directional antenna(s) of the non-root Bridge(s) in the network.
When the
LED RSSI Monitor
is
Enabled
on a given radio, all
other monitoring functions of both of the front-panel LEDs for
that radio (described in Section 5.6.2) are disabled.
Then, as you point a directional antenna of a non-root Bridge
toward the root Bridge, the lower LED for that radio dynamically
indicates the strength of the signal received from the root
Bridge, as shown in Table 3.1.
The
LED RSSI Monitor
is
Disabled
by default.
3.3.3
Configuring Basic Radio Settings
1
Log on to the Bridge GUI
admin
account and select
RADIO
SETTINGS
from the menu on the left.
2
On the
RADIO
SETTINGS
screen, in the column that
corresponds to the radio you want to configure, enter new
values into the relevant fields (described in sections 3.3.1
and 3.3.2).
NOTE:
When you
change
TxPower
from
Auto
to another
value, the change takes
effect immediately.
When you change the
setting from another
value to
Auto
, you must
reboot Bridge in order
to effect the change.
3
Click
Apply
at the bottom of the screen.
4
If a system prompt instructs you to reboot, click
OK
.
5
If you changed
TxPower
to
Auto
, or you were prompted to
reboot the Bridge, follow the instructions in Section 4.7.
3.3.4
Virtual Radio Interface Settings
A radio with a
radio mode
of
Bridge
, whether it is configured as
a root or a non-root bridge, can comprise only a single Virtual
Access Point (or
VAP
), with its single associated SSID.
A radio with a
radio mode
of
AP
, can comprise up to four VAPs
each with its own SSID and associated settings.
By default, only one VAP is configured per radio, regardless of
the radio
Mode
settings. You can however observe the added,
Table 3.1. RSSI Behaviors and Meanings in Radio LEDs
Behavior
Meaning
off
no connection
slow green flash (approx. 1 Hz)
poor connection (signal level
≤ -85 dBm)
fast green flash (approx. 4 Hz)
good connection (signal level > -85 dBm but < -60 dBm)
steady green
excellent connection (signal level > -60 dBm)
