Fortress Bridge: Command-Line Interface
99
6.4.9.2 Internal LAN Switch Port 802.1X Settings
You can individually configure each of the ports of the Bridge’s
internal LAN switch to require that a connected device is an
802.1X supplicant successfully authenticated by the 802.1X
authentication server configured for the Bridge (Section 6.4.9).
View current LAN port settings with the show command:
[GW]> show 8021X
Lan1:off
Lan2:off
Lan3:off
Lan4:off
Lan5:off
Lan6:off
Lan7:off
Lan8:off
AuthServer:127.0.0.1
AuthPort:1812
The Lan numbers shown correspond to the Bridge’s front-panel
switch port labeling. By default, the 802.1X authentication
requirement is turned
off for all eight ports.
Use the set command with just the 8021X argument to
configure the 802.1X server interactively. The Bridge CLI
presents one field at a time, and you can either backspace over
the existing value for a given field and enter a new value or
strike
Enter ↵ to leave the value unchanged and go on to the
next field.
Alternatively, you can use the set 8021X command with valid
arguments to change 802.1X LAN port settings:
[GW]> set 8021X [lan1|2|3|4|5|6|7|8] [on|off]
Changing LAN port settings requires you to reboot the Bridge
to effect your changes.
The show 8021X and set 8021X commands are valid only in
GW (gateway) mode (refer to Section 6.1.1 for more detail).
6.5 Administration in the Bridge CLI
6.5.1 Trusted Devices in the CLI
View configured Trusted Devices with show td :
[GW]> show td
NAME IP MAC PORT
guests 123.45.6.7 11:22:33:44:55:66 80
audit 123.67.8.9 33:44:55:66:77:88 80,443
print1 234.56.7.8 22:33:44:55:66:77 23
Total TD: 3
Use the add and del (delete) commands to manage Trusted
Devices for the Bridge-secured WLAN, as described in the
following sections.
