SYSTEM CONFIGURATION
Standard type
Note 1: Power Kit FSV-2403 (option, installed in
processor unit) required to connect CS-120A.
TRANSCEIVER
UNIT
FSV-241E
POWER
SUPPLY
UNIT
FSV-242
100/110/115/
220/230 VAC,
1
φ,
50/60 Hz
220 VAC,
3
φ,
50/60 Hz
PROCESSOR UNIT
FSV-2402
Loudspeaker
Sub Monitor
Echo Sounder,
Current Indicator,
other
Navigator 1
Navigator 2
AD Converter
AD-10
Current
Indicator
Current
Indicator/Log
E/S Interface
VI-1100A
Net Recorder
VI-1100A
Net Sonde
Junction Box
CS-170 VI-1100A
Net Sonde
External
Interface CS-120A
(already installed)
Note 1
100/110/115/
220/230 VAC,
1
φ,
50/60 Hz
CONTROL UNIT
FSV-2401
MONITOR
UNIT
FSV-2400
Local Supply
Option
Hull unit Specifications
FSV-247 1200 mm stroke
FSV-248 1600 mm stroke HULL UNIT
Gyrocompass
Cable for
Extension Kit
FSV-2451
FSV-2452
