Furuno FSV-24 - Manual (Page 40)

2-12
8 cm
Soldering side
Soldering-side
Connector case
Connector case
1 cm 2 cm
3 mm
Shield
2 cm
3mm
Shield
Vinyl sheath
Vinyl sheath
Vinyl sheath
Armor
Solder unused cores and
earth to braided shield.
Solder unused cores and
earh wire to braided shieeld.
Wind shield
tape.
Clamp shielding tape with
connector clamp for grounding.
Soldering
Wind vinyl tape.
Wind vinyl tape
Clamp fixing screw
Clamp fixing screw
Clamp
Clamp
Set screw
Set screw
J9 (ES1) : SRCN6A16-7P
J12 (ES2/NET) : SRCN6A16-10P
Cable with armor
J5 (CIF1) : SRCN6A13-5P
J7 (GYRO) : SRCN6A16-10P
J8 (LOG) : SRCN6A13-3P
J10 (FNZ) : SRCN6A21-10P
J13 (EXT-KP) : SRCN6A21-10S
Cable without armor
