1-18
1.7 Mounting the Cable for Extension Kit (option)
For extension of the transducer cable between the hull unit and the transceiver
unit, use the extension cable kit (option). The kit is available in 5 and 15 meter
lengths.
Name: Cable for Extension Kit, Type: FSV-2451, Code No.: 000-067-030
Name Type Code No. Qty Remarks
Junction box FSV-245 000-067-032 1
10S2138*5m* 000-145-350 1
10S2139*5m* 000-145-354 1 Cable assembly
10S2144*12.9m* 000-145-360 1
Name: Cable for Extension Kit, Type: FSV-2452, Code No.: 000-067-031
Name Type Code No. Qty Remarks
Junction box FSV-245 000-067-032 1
10S2138*15m* 000-145-351 1
10S2139*15m* 000-145-355 1
Cable
assembly
10S2144*22.9m* 000-145-361 1
Fasten the Junction Box to bulkhead with 4 bolts (M8, local supply).
Junction box
