CAUTION
Maximum speed while the transducer is
projected and being raised or lowered
is as below, to prevent damage to the
transducer.
Projected Raising/
Lowering
1200 mm stroke Max. 18 kt Max. 15 kt
1600 mm stroke Max. 15 kt Max. 12 kt
Observe the following compass safe
distances to prevent interference to a
magnetic compass:
Other equipment should be positioned at
least 7 m away from a magnetic compass.
Processor Unit
Control Unit
Monitor Unit
Standard
compass
Steering
compass
1.55 m 1.05 m
0.20 m 0.15 m
1.25 m 0.85 m
