setupfru(8)
280 SPARC Enterprise Mx000 Servers XSCF Reference Manual • Last Revised September 2008
OPERANDS The following operands are supported:
EXTENDED
DESCRIPTION
■ In the M8000/M9000 server, the Quad-XSB configuration cannot be set in
memory mirror mode.
■ To set up an already mounted PSB again, all XSBs comprising the target PSB
must have been disconnected from the domain configuration and placed under
the system board pool. See the deleteboard(8) command for information on
how to disconnect XSBs from the domain configuration.
■ The configuration of the PSB varies according to the system as shown below.
■
In the M8000/M9000 servers, the PSB consists of one CPU/memory board
unit and one I/O unit in combination.
■
In the M4000/M5000 servers, the PSB consists of one CPU module and one
memory module logically divided into two on the motherboard unit, and one
I/O module.
■ The current PSB settings can be checked by using the showfru(8) command.
EXAMPLES EXAMPLE 1 Configures PSB#00 as a Quad-XSB (with memory in non-mirror mode be-
cause the memory mirror mode setting is omitted).
EXIT STATUS The following exit values are returned:
SEE ALSO addboard(8) , deleteboard(8), moveboard(8), setdcl(8), showboards(8),
showdcl(8) , showdevices(8), showfru(8)
device Specifies the device to be set up. Only the following device can be
specified:
sb Physical system board (PSB)
location Specifies the location of the device.
sb Integer from 0–15. Specify only one location.
XSCF> setupfru -x 4 sb 0
0 Successful completion.
>0 An error occurred.
