19-inch rack Model 1624 (expansion/without stabilizer)
No. Description
(1) Top view
(2) Rear view
(3) Right side view
(4) Front view
FIGURE A.19 Outline drawing of the 19-inch rack Model 1624 (expansion/without stabilizer)
A.3.3 Bottom view drawings of 19-inch racks
This section provides bottom view drawings of 19-inch racks.
Bottom view drawing of the (standard) 19-inch rack
Bottom view drawing of the (slim) 19-inch rack
