A.3 Fujitsu 19-inch Racks
This section shows the types, outline drawings, and bottom view drawings of Fujitsu 19-inch racks.
- A.3.1 Types of 19-inch rack
- A.3.2 Outline drawings of 19-inch racks
- A.3.3 Bottom view drawings of 19-inch racks
Remarks
For the outline drawings and dimensions of the models 2742/2737/2724/2642/2624/2616, contact the distributor
where you purchased your product, or your sales representative.
A.3.1 Types of 19-inch rack
TABLE A.5 Types of 19-inch rack lists the racks in which the PRIMEQUEST 1000 series server and PCI_Box
can be mounted.
Remarks
For the racks on which models can be mounted, the models 2742/2737/2724/2642/2624/2616 are also available.
For details, contact the distributor where you purchased your product, or your sales representative.
TABLE A.5 Types of 19-inch rack
Item
No.
Model name Product name Width
(*1)
Depth
(*1)
Height
(*1)
Total
weight
capacity
(*2)(*3)
Rack
weight
(*2)
Total
rack
weight
(*2)
Remarks
1 19R-174A1 19-inch rack
Model 1740
(base/with
stabilizer)
(standard)
700
(27.6)
1272
(50.1)
2000
(78.8)
800
(1760)
143
(315)
(*4)
943
(2075)
40U
with side
boards
2 19R-174A2 19-inch rack
Model 1740
(base/without
stabilizer)
(standard)
700
(27.6)
1050
(41.3)
2000
(78.8)
800
(1760)
135
(297)
935
(2057)
40U
with side
boards
3 19R-174B1 19-inch rack
Model 1740
(expansion/
with
stabilizer)
(standard)
(*5)
700
(27.6)
1272
(50.1)
2000
(78.8)
800
(1760)
110
(242)
(*4)
910
(2002)
40U
without side
boards
4 19R-174B2 19-inch rack
Model 1740
700
(27.6)
1050
(41.3)
2000
(78.8)
800
(1760)
102
(224)
902
(1984)
40U
