3.1 Elevator Load Conditions
The rack with the device mounted is wider than the average computer. Therefore, to use an elevator to carry in the
rack, the rack may need the side boards or doors removed before loading on the elevator. When using an elevator
to carry in the rack, see the elevator load conditions in TABLE 3.1 Elevator load conditions and confirm that you
are properly loading the rack on the elevator.
TABLE 3.1 Elevator load conditions
Elevator code Load
capacity
[kg]
Width
(*1)
Depth
(*1)
Height
(*1)
Width
(*2)
Height
(*2)
Rack
Models 2742/2737/2724/
2642/2624/2616
Models 1740/1640/1624
P-6-C0 450 1400 850 2300 800 2100 Cannot be loaded
P-9-C0 600 1400 1100 2300 800 2100 Cannot be loaded
P-11-C0 750 1400 1350 2300 800 2100 Can be loaded
P-13-C0 900 1600 1350 2300 900 2100 Can be loaded
P-15-C0 1000 1600
1800
1500
1300
2300 900
1000
2100 Can be loaded
P-17-C0 1150 1800
2000
1500
1350
2300 1000
1100
2100 Can be loaded
P-20-C0 1350 1800
2000
1700
1500
2300 1000
1100
2100 Can be loaded
P-24-C0 1600 2000
2150
1750
1600
2300 1100 2100 Can be loaded
*1 Interior dimensions of the cab [mm]
*2 Door opening dimensions [mm]
PRIMEQUEST 1000 Series Hardware Installation Manual
CHAPTER 3 Notes on Carrying In and Installing the Product
44 C122-H004-07EN
