No. Description
(6) Top cover
FIGURE A.16 Outline drawing of the 19-inch rack Model 1624 (base/with stabilizer)
19-inch rack Model 1624 (base/without stabilizer)
No. Description
(1) Top view
(2) Rear view
(3) Right side view
(4) Front view
FIGURE A.17 Outline drawing of the 19-inch rack Model 1624 (base/without stabilizer)
19-inch rack Model 1624 (expansion/with stabilizer)
