2.4.3 Connections between the power distribution box and distribution panel
TABLE 2.7 Specifications of the power cable between the power distribution box and distribution panel lists the
specifications of power cables between the power distribution box and distribution panel.
TABLE 2.7 Specifications of the power cable between the power distribution box and distribution panel
Destination Plug type Remarks
For use in countries
other than Japan
NEMA L6-30P
Shape of receptacle
outlet
NEMA L6-30R (North America
only)
30A-220VAC
For use in Brazil IEC60309-32A
Shape of receptacle
outlet
IEC60309
32A-250VAC
Remarks
- Connect the device with only the power cable supplied with the device. Do not use the power cable supplied
with the device to connect a different product.
- Use a plug that matches the shape of the receptacle outlet.
