- The numbers in parentheses ( ) correspond to the cable numbers in TABLE 2.3 Cables (for the basic interfaces
and peripheral devices) (PRIMEQUEST 1800E2) .
- For a 10GBase-CR cable, use the 10GBase-CR (TWINAX) cable specified for the connected switch product.
List of cables
Determine the length of an external interface cable by considering the extra length required for laying the cable
inside the cabinet.
TABLE 2.3 Cables (for the basic interfaces and peripheral devices) (PRIMEQUEST 1800E2)
No. Name Model name Commercially available types Length
(1) Twisted-pair cable
(Category 5
UTP cable)
TPCBL-B005 Sold separately: Select from lengths of 5, 10,
15, 30, 50, and 100 m.
100Base-TX and 10Base-T connections use
this cable (Category 5).
RJ45 8Pin - RJ45 8Pin
5 m
TPCBL-B010 10 m
TPCBL-B015 15 m
TPCBL-B030 30 m
TPCBL-B050 50 m
TPCBL-B100 100 m
(2) Enhanced Category 5
UTP cable
TPCBL-C005 Sold separately: Select from lengths of 5, 10,
15, 30, 50, and 100 m.
1000Base-T, 100Base-TX, and 10Base-
T connections use this cable (Category 5e).
RJ45 8Pin - RJ45 8Pin
5 m
TPCBL-C010 10 m
TPCBL-C015 15 m
TPCBL-C030 30 m
TPCBL-C050 50 m
TPCBL-C100 100 m
(3) SAS cable CBL-SASM1U Sold separately: Select from lengths of 1.5
and 3 m.
miniSAS (SFF-8088) - miniSAS (SFF-8088)
For use in countries other than Japan
1.5 m
CBL-SASM3U 3 m
(4) RS232C cable
(D-Sub 9Pin-9Pin,
crossover cable)
FMV-CBL501 1.5 m
(5) PCI Express cable Included with
PCI_Box
2 m
(6) Multimode
Fibre Channel cable
CBL-MLLB02 Sold separately: Select from lengths of 2, 5,
and 15 m.
Dual LC connector - Dual LC connector
Without cable insulation
2 m
CBL-MLLB05 5 m
CBL-MLLB15 15 m
CBL-MLLC05 Sold separately: Select from lengths of 5, 10,
20, 30, 40, and 50 m.
Dual LC connector - Dual LC connector
With cable insulation
5 m
CBL-MLLC10 10 m
CBL-MLLC20 20 m
CBL-MLLC30 30 m
