IVCE-C608/IVCE-C604/IVCME-C604 Capture Card
Page 42
NOTE:
Audio bypass is not available in the current version.
6.3.3 Video Out (IVCE-C608 and IVCE-C604 Only)
The Video Out function allows users to display video (recorded by the test suite) on
display devices through the output ports of the IVCE-C608 or the IVCE-C604. To do this,
follow the steps below.
NOTE:
Please make sure to stop the video by pass before using the video out
function.
Step 1:
Connect the video input source to the video input port of the IVCE-C608 or the
IVCE-C604.
Step 2:
Connect the BNC cable from the display device to the BNC output port of the
IVCE-C608 or the IVCE-C604.
Step 3:
Launch the IEI Video Capture Test Suite.
Step 4:
Select the capture card type: PCIE. Click the Get Cards button. The capture
cards connected to the system shows. Select one capture card from the list.
Step 5:
Click the Video Out button:
Step 6:
The Video Out window appears.
