4
Shared Storage Configurations
Configurations:
Basic See "Basic Configuration Cabling Diagrams with Single or Cascaded
Hubs."
Redundant See "Redundant Configuration Cabling Diagrams with Single or
Cascaded Hubs."
Fibre Channel Hubs:
Model A3724A HP 10-port Short Wave Fibre Channel (FC) Hub
A4839A HP 10-port Long Wave FC Hub
No. of Hubs Basic Configuration: 1 or 2
Redundant Configuration: 2 or 4 with 1 min. or 2. max. per FC
Arbitrated Loop.
Disk Arrays (See Shared
Storage.):
No. of Disk Arrays 1-8
No. of Controllers 1 per Disk Array for Basic Configuration.
2 per Disk Array for Redundant Configuration.
LANs
Intra-cluster (Heartbeat) LAN Client LAN
LAN connection HP D5954A crossover cable or any
equivalent Any LAN
The intra-cluster LAN may only be used for
cluster node communication via a crossover
cable. It may not be used for client
communication.
NIC:
Model HP D5013A (10/100TX PCI) Any that is on both the HP
Tested Products List and the
Microsoft Hardware
Compatibility List.
Driver 3.27.00.0001 or later (Do not enable FEC
Features.) Any driver
NOTE: If the NIC used is the
same as the Intra-cluster LAN,
then the Client LAN must use the
same driver as the Intra-cluster
LAN.
No. of NICs 1 1 minimum
SPU I\O slot P5 P6
