1 Setting Up and Using Your PC Workstation

The MaxiLife Status Panel

The MaxiLife panel is located on the front of your PC Workstation.

HP MaxiLife and its
Liquid Crystal
Display (LCD)

HP MaxiLife and its LCD screen helps you diagnose problems with your PC
Workstation and provides system information you may need to obtain
support. Press one of the LCD control buttons to display the menu. Use

to scroll through the menu items and

to select the item required.

For more information on using the LCD, refer to “Using HP MaxiLife to
Diagnose Problems” on page 54.

Hard Disk Activity
Light

This light flickers when your hard disk drive is being accessed.

Power On/Off
Button

Reset Button

LCD Control Buttons

Hard Disk
Activity Light
