Page 12

1 Setting Up and Using Your PC Workstation

Connecting Devices

For your own safety, it is recommended that you first read the warning
notices on pages 6 and 7.

NOTE

Universal Serial Bus (USB). Connectors can be used for USB
accessories. (For information about HP accessories, connect to HP’s web
site

www.hp.com/go/pcaccessories

.) Most USB accessories are

automatically configured as soon as they are physically attached to the PC
Workstation. USB accessories are not supported by all operating systems.

Line Out Jack. The internal audio speaker is deactivated when you use
the Line Out jack. External speakers should have a built-in power supply.

Parallel port

Serial port A

Keyboard connector

Dual USB connectors

Serial port B

MIDI

connector

Line Out connector

Line In connector

Microphone connector

Mouse connector

Display connector
