PIM-SM (Sparse Mode)
Configuration Steps for PIM-SM
4. Optional: In the PIM router context, change one or more of the traffic
control settings in the following table.
Options Accessed in
Router PIM Context
Operation
rp-candidate group-prefix
Enter an address and mask to define an additional
< group-addr/group-mask >
multicast group or a range of groups.
rp-candidate hold-time
Tells the BSR how long it should expect the sending
< 30 - 255 >
Candidate-RP router to be operative. (Default: 150; 0 if
router is not a candidate)
rp-candidate priority < 0 - 255 > Changes the priority for the Candidate-RP router. When
multiple C-RPs are configured for the same multicast
group(s), the priority determines which router
becomes the RP for such groups. A smaller value
means a higher priority. (Default: 192)
[ no ] spt-threshold
Disable or enable the router’s ability to switch multicast
traffic flows to the shortest path tree. (Default:
enabled)
join-prune-interval < 5 - 65535 > Optional: Globally change the interval for the frequency
(page 4-30)
at which join and prune messages are forwarded on
the router’s VLAN interfaces. (Default: 60 seconds)
trap
Optional: Enable or disable PIM traps. (Default:
< neighbor-loss |
disabled.)
hardware-mrt-full |
software-mrt-full | all >
(page 4-41)
4-24
