Component identification 15
System LED and
Color Internal Health
LED Color Status
Overtemperature
(amber)
Amber The Health Driver has detected a cautionary temperature
level.
Red The server has detected a hardware critical temperature
level.
Fan module (amber) Red The minimum fan requirements are not being met in one or
more of the fan modules. One or more fans have failed or
are missing.
Power supply (amber) Red One or more of the following conditions may exist:
• There is no AC power.
• The power supply has failed.
Amber There is a power supply mismatch at POST.
DIMM slots
DIMM slots are numbered sequentially (1 through 9) for each processor. The supported AMP modes use
the letter assignments for population guidelines.
DIMM identification
IMPORTANT: This server does not support mixing RDIMMs and UDIMMs. Attempting to mix
these two types causes the server to halt during BIOS initialization.
