Service
Deskside Side Panel
96
Service
Deskside Side Panel
To replace a deskside side panel (Figure 35):
1. Remove the modules from the two lower bay slots.
2. Locate the removal access hole inside the panel.
3. Holding the outside of the side panel and pressing slightly upward, insert a small screwdriver into the
removal access hole in the direction of the arrow, pressing the panel outward.
4. Move the side panel upward to release it from the hook slots at the top and bottom of the enclosure.
5. Replace the side panel by positioning the hooks into the slots and pushing the panel downward.
Figure 35. Locating the Side Panel Removal Access Hole
