HP A3312A - Manual (Page 98)

Service
Door Assembly
92
Service
Door Assembly
Deskside Door
To replace the deskside door (Figure 32):
1. Unlock the security lock.
2. Open the door to 90 degrees from the closed position.
3. Move the hinged side toward the left and rear.
4. Remove the door by lifting it up and out toward the front.
5. Replace the door by lowering the hinges onto the enclosure hinge bracket.
NOTE! The replacement door includes a switch cover, security lock, two light pipes, and a
latch. Keys are not included with the replacement door.
Figure 32. Replacing the Deskside Door
