Service
AC Power Adapter
106
Service
Rackmount AC Power Adapter
To replace the rackmount ac power adapter (Figure 41):
1. Remove the power module.
2. Remove two T10 screws (item 1)
3. Remove two star washers (item 3).
4. Remove the ac power adapter (item 2).
5. Replace the ac power adapter in reverse order, ensuring the lock washers are located between the ac
power adapter and the rear of the chassis.
NOTE! Put the screws and washers on the power adapter, then fasten the entire assembly at
once.
Figure 41. Replacing the Rackmount AC Power Adapter
1 - M3/T10 Screw (2) 3 - Star Washer (2)
2 - AC Power Adapter
