1)
Also compatible with the frame rate 1/1.001.
2)
This signal is described as “equivalent to the 4K signal” in this manual.
3)
“Enhanced Format” must be selected in the “HDMI In. Setting” (page 30). Also, when using this input signal, use the Premium High-
Speed HDMI cable. (30P, 25P, 24P signals are only for the 4:4:4 RGB/YCbCr 10/12bit signal.)
4) The 4:4:4(YCbCr)12/10bit signal is displayed after converting to the 4:2:2(YCbCr)12/10bit signal. If it is not displayed correctly, use the
4:4:4(YCbCr)8bit signal or 4:2:2(YCbCr)12bit signal as the input signal.
5) The 4:4:4(RGB)12/10bit signal is displayed after converting to the 4:2:2(YCbCr)12/10bit signal. If it is not displayed correctly, use the
4:4:4(RGB)8bit signal or 4:2:2(YCbCr)12bit signal as the input signal. However, when AVI Info (signal information) cannot be detected
and/or “RGB/YCC Range” is set to “Full,” it is displayed as the 4:4:4(RGB)8bit signal if the input signal is determined as the Limited
signal.
6) This signal system is not described in EDID (Extended Display Identification Data).
Enhanced Monitor Out - Input/Output Format Compatibility Table
SDI Input Signals
3840 × 2160/50P
2)
4 : 4 : 4 (RGB)
8bit
3)
4 : 4 : 4 (YCbCr)
8bit
3)
4 : 2 : 2 (YCbCr)
12bit
3)
4 : 2 : 0 (YCbCr)
10/8bit
4096 × 2160/60P
1)
2)
4 : 4 : 4 (RGB)
8bit
3)
4 : 4 : 4 (YCbCr)
8bit
3)
4 : 2 : 2 (YCbCr)
12bit
3)
4 : 2 : 0 (YCbCr)
10/8bit
4096 × 2160/50P
2)
4 : 4 : 4 (RGB)
8bit
3)
4 : 4 : 4 (YCbCr)
8bit
3)
4 : 2 : 2 (YCbCr)
12bit
3)
4 : 2 : 0 (YCbCr)
10/8bit
800 × 600/60P
4 : 4 : 4 (RGB)
12/10/8bit
4 : 4 : 4 (YCbCr)
12/10/8bit
4 : 2 : 2 (YCbCr)
12bit
1024 × 768/60P
4 : 4 : 4 (RGB)
12/10/8bit
4 : 4 : 4 (YCbCr)
12/10/8bit
4 : 2 : 2 (YCbCr)
12bit
Signal System
Signal Structure
SDI Interface
Signal Structure
Signal System
1)
Input signal No
12G-SDI Single-Link
Square/2SI
4:2:2 (YCbCr)
10bit
3840 × 2160
50P, 60P
2)
3G-SDI Quad-Link Level A
3G-SDI Quad-Link Level B
12G-SDI Single-Link
Square/2SI
4:2:2 (YCbCr)
10bit
4096 × 2160
48P
2)
, 50P, 60P
2)
3G-SDI Quad-Link Level A
3G-SDI Quad-Link Level B
12G-SDI Single-Link
Square/2SI
4:4:4 (RGB)
4:4:4 (YCbCr)
10bit, 12bit
10bit, 12bit
3840 × 2160
24P
2)
, 25P, 30P
2)
3G-SDI Quad-Link Level A
3G-SDI Quad-Link Level B
6G-SDI Single-Link
Square/2SI
4:2:2 (YCbCr)
10bit
3G-SDI Dual-Link Level B-DS
HD-SDI Quad-Link
Square
