PID specifications
This unit superimposes PID on SDI signals output from the ENHANCED MONITOR OUT connector
according to the output signal format. The following shows the Transfer Characteristics, Colorimetry, and
Bit Depth of PID when the User LUT function and HDR-SDR conversion function are ON/OFF.
User LUT function
HDR-SDR Conversion
function
Output SDI Interface
Transfer Characteristics Processing
OFF
OFF
12G/6G/3G-SDI
Input signal Byte2: Retains bit [5: 4]
However, when an S-Log3 signal is output,
Byte2:bit[5:4] will be 3h(Unspecified).
HD-SDI 1080-line
HD-SDI 720-line
Not applicable
ON
OFF
12G/6G/3G-SDI
HD-SDI 1080-line
Replaced by the EOTF setting value in "VPID/HDMI
Auto," "SR Live Auto" or "EOTF" in "Ch. Setting."
EOTF setting value
Transfer characteristics
Byte2: bit [5:4]
2.2
SDR-TV
2.4
SDR-TV
2.6
SDR-TV
2.4(HDR)
Unspecified
S-Log3
Unspecified
SMPTE ST 2084(PQ)
PQ
ITU-R BT.2100(HLG)
HLG
S-Log3(Live HDR)
Unspecified
HD-SDI 720-line
Not applicable
OFF
ON
12G/6G/3G-SDI
HD-SDI 1080-line
Replaced to the setting value of "Out. OETF" in
"Conv. Preset." (The following are fixed values.)
Out. OETF setting value
Transfer characteristics
Byte2: bit [5:4]
ON
2.4
SDR-TV
HD-SDI 720-line
Not applicable
User LUT function
HDR-SDR Conversion
function
Output SDI Interface
Colorimetry processing
OFF
OFF
12G/6G/3G-SDI
Input signal Byte3: Retains bit [5: 4]
HD-SDI 1080-line
Input signal Byte3: Retains bit [7] and bit [4]
HD-SDI 720-line
Not applicable
