149
Battery pack (1)
AC adapter/charger (1)
USB cable (1)
Lens hood (1)
Large eyecup (1)
Shoulder strap (1)
CD-ROM “Operating instructions” (1)
Before Using This Unit (1)
Warranty booklet (1)
Software Downloads
When the unit is used with a PC connection,
download device drivers, plug-ins, and
application software, where applicable, from the
Sony Professional products web site.
Sony Professional products web site homepage:
U.S.A.
http://pro.sony.com
Canada http://www.sonybiz.ca
Latin America http://sonypro-latin.com
Europe, Middle East and Africa
http://www.pro.sony.eu
Japan http://www.sonybsc.com
Asia Pacific http://pro.sony-asia.com
Korea http://bp.sony.co.kr
China http://pro.sony.com.cn
Although the data regarding recorded materials
are stored over multiple files and folders, you can
easily handle the clips without considering its
data and directory structure, by using the
dedicated application software.
Note
• If you perform operations on clips, such as copying the
clips on the SxS memory card using Explorer
(Windows) or Finder (Macintosh), the subsidiary data
contained by the clips may not be maintained.
Design and specifications are subject to change
without notice.
Timecode input
BNC type (1), switchable with TC OUT
connector
0.5 V to 18 Vp-p, 3.3 k
Ω
Timecode output
BNC type (1), switchable with TC IN connector
1.0 Vp-p, 75
Ω
GENLOCK input
BNC type (1), switchable with VIDEO OUT
connector
1.0 Vp-p, 75
Ω
USB connector
Multi/Micro USB (1)
Host: USB 3.0/2.0 type A (1), USB 2.0 type A
(1)
Headphone output
Stereo mini jack (1)
–16 dBu, 16
Ω
Speaker output
Monaural
Output: 500 mW
DC input
DC jack
HDMI output
HDMI connector (type A)
REMOTE connector
Stereo sub-mini jack (ø2.5 mm)
Wired LAN connector
RJ-45 (1), 1000BASE-T, 100BASE-T,
10BASE-T
Display
Viewfinder
Screen size: 1.3 cm (0.5-inch type)
Effective pixels: Approx. 2.36M dots
LCD screen
Screen size: 8.8 cm (3.5-inch type)
Effective pixels: Approx. 1.56M dots
Internal microphone
Internal microphone
Omnidirectional stereo electret condenser
microphone
Media slots
Type
ExpressCard/34 (2)
SD/MS (1)
Supplied accessories
