You can check the settings and status of the
camcorder on the status screen.
Status screen operations
To display the status screen:
• Push the STATUS CHECK button.
To switch the status screen:
• Turn the SEL/SET dial or press the
V / v button.
To hide the status screen:
• Push the STATUS CHECK button.
Camera Status screen
Displays the picture quality, zoom settings, and
status.
Audio Status screen
Displays the input setting, audio level meter, and
wind noise reduction filter setting for each
channel.
Station mode Wi-Fi
connected
Wi-Fi signal
strength (4
levels)
Wi-Fi
disconnected
(incl. during
setup)
Wi-Fi
connection
error
Modem 3G/4G signal
strength (5
levels)
3 levels for
modems
without signal
strength
detection 3G connected
–
4G connected
–
Network
connection (3G/
4G indeterminate)
–
3G/4G
disconnected
(incl. during
setup)
3G/4G
connection
error
Wired LAN LAN connected
LAN
connection
error
Status screen
Network
mode Connection
status Icon
White Switch White balance memory B
adjustment value
White Switch White balance memory A
adjustment value
White Switch Preset White setting
ND Preset1 to 3 setting for ND
Filter
Zebra1 Zebra1 On/Off setting and
level
Zebra2 Zebra2 On/Off setting and
level
Gamma Gamma category and curve
Gain Switch Gain, Gain,
Gain setting
Handle Zoom Speed Handle Zoom setting
Scene File Current scene file and file ID
CH1 level meter CH1 level meter
CH1 Input Source CH1 input source
CH1 Ref./Sens. CH1 input reference level
CH1 Wind Filter CH1 microphone wind
reduction filter setting
CH2 level meter CH2 level meter
CH2 Input Source CH2 input source
CH2 Ref./Sens. CH2 input reference level
CH2 Wind Filter CH2 microphone wind
reduction filter setting
CH3 level meter CH3 level meter
CH3 Input Source CH3 input source
CH3 Ref./Sens. CH3 input reference level
CH3 Wind Filter CH3 microphone wind
reduction filter setting
CH4 level meter CH4 level meter
CH4 Input Source CH4 input source
CH4 Ref./Sens. CH4 input reference level
CH4 Wind Filter CH4 microphone wind
reduction filter setting
HDMI Output CH HDMI output audio channel
combination setting
Analog Output CH Analog output audio channel
combination setting
Monitor CH Monitor channel setting
