User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
Figure 4-9-10 IGMP Filter and Throttling Port Configuration page screenshot
The page includes the following fields:
Object Description
• Profile Selects an existing profile number to assign to an interface.
• Max Multicast Groups Sets the maximum number of multicast groups an interface can join at the same
time.
Range: 0-255;
Default: 255
• Current Multicast
Groups
Displays the current number of multicast groups the interface has joined.
• Throttling Action Mode Sets the action to take when the maximum number of multicast groups for the
interface has been exceeded.
(Default: Deny)
-deny - The new multicast group join report is dropped.
-replace - The new multicast group replaces an existing group.
• Throttling Status Indicates if the throttling action has been implemented on the interface.
Options:
- True
- False
• Trunk Indicates if a port is a trunk member.
