User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
Table
• Interface
Port or trunk associated with the device assigned a static address.
• MAC Address
Physical address of a device mapped to this interface.
• VLAN
ID of configured VLAN (1-4094).
Static MAC Address example:
Figure 4-6-2 Static Addresses page screenshot
4.6.2 Dynamic Addresses
The Dynamic Address Table contains the MAC addresses learned by monitoring the source address for traffic entering the
switch. When the destination address for inbound traffic is found in the database, the packets intended for that address are
forwarded directly to the associated port. Otherwise, the traffic is flooded to all ports.
Command Sequence - Specify the search type (i.e., mark the Interface, MAC Address, or VLAN checkbox), select the method
of sorting the displayed addresses, and then click Query.
