User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
Figure 4-9-2 IGMP Immediate Leave page screenshot
The page includes the following fields:
Object
Description
• VLAN ID
VLAN Identifier.
(Range: 1-4094)
• Immediate Leave
Sets the status for immediate leave on the specified VLAN.
(Default: Disabled)
4.9.1.3 Multicast Router Port Information
Multicast routers that are attached to ports on the Managed Switch use information obtained from IGMP, along with a multicast
routing protocol such as DVMRP or PIM, to support IP multicasting across the Internet. These routers may be dynamically
discovered by the switch or statically assigned to an interface on the switch.
You can use the Multicast Router Port Information page to display the ports on this Managed Switch attached to a neighboring
multicast router/switch for each VLAN ID.
Figure 4-9-3 Multicast Router Port Information page screenshot
