16 WatchOUT 315DT Installation Manual
Quick Keys Parameter Default
[2][0][3][zzz]
[3][1]..[7] MW Range options
1) Minimum
2) 20%
3) 40%
4) 60% 5) 80%
6) Maximum 7) Trimmer (MW is defined
by the trimmer setting on
the PCB)
[2][0][3][zzz]
[4]
Anti-Mask sensitivity Low sensitivity
Defines the sensitivity of the active IR AM
[2][0][3][zzz]
[4][1]..[2]
Anti-Mask sensitivity option
1) Low Sensitivity 2) High Sensitivity
[2][0][3][zzz]
[5] Lens Type Wide Angle
Defines the actual Lens of the detector
[2][0][3][zzz]
[5][1]..[2] Lens Type Options
1) Wide Angle 2) Barrier / Long Range
[2][0][3][zzz]
[6] Anti-Mask Enable
Defines the operation of Anti Masking detection
[2][0][3][zzz]
[6][1]..[2] Anti-Mask Options
1) Disable 2) Enable (Default)
[2][0][3][zzz]
[7] Arm/Disarm No
Defines the operation of the LEDs anti masking detections while the detector
is armed
[2][0][3][zzz]
[7][1] No
Active IR AM and Proximity AM (Anti masking) is enabled
LEDs behave according to the LEDs parameter definition
[2][0][3][zzz]
[7][2] Yes
Active IR AM and Proximity AM (Anti masking) is disabled
LEDs are disabled
[2][0][3][zzz]
[8] Proximity AM Disable
Defines the operation of the Proximity Anti Masking detection
[2][0][3][zzz]
[8][1]..[2] Proximity AM Options
1) Disable (Default) 2) Enable
NOTE: Disable Proximity AM during heavy rain (if WatchOUT 315DT is not
sheltered) to prevent Proximity AM alerts.
System Parameters
System: System Control
Quick Keys Parameter Default:
[1][2][36] IR AM=Tamper No
Used to determine the operation of Active IR Anti Masking detection
Yes: Active IR Anti mask detection will activate tamper alarm.
No: Active IR Anti mask detection will be regarded as trouble event.
[1][2][37] Prox AM=Tamper No
Used to determine the operation of the Proximity Anti Masking detection
Yes: Proximity Anti mask detection will activate tamper alarm.
No: Proximity Anti mask detection will be regarded as a trouble event.
