BUS Mode Installation
Introduction
The information in this section relates to WatchOUT 315DT installation in BUS Mode only. Up to
32 BUS detectors can be installed on the ProSYS RS485 BUS, saving cabling time and enabling
remote control and diagnostics.
Terminal Wiring
+,- Used for the connection of 12VDC power supply. Connect the (+) terminal to
the AUX RED and the (–) terminal to the COM BLK of the ProSYS terminals
YELLOW Used for data communication with the ProSYS. Connect to the terminal to the
BUS YEL of the ProSYS
GREEN Used for data communication with the ProSYS. Connect to the terminal to the
BUS GRN of the ProSYS
TAMPER Used for the wiring for tamper detection, see below
LED
ENABLE Used for the wiring for tamper detection, see below
Note:
All terminals that are not mentioned in the table above are unused.
Cover and Back Tamper
+ - SET/
UNSET
LEDs
ENABLE
AM
YEL
FREE ALARM
TAMPER
GREEN
FREE
DUST TEST
COM
BLK
BUS
GRN YEL
BUS Mode:
Cover + Back tamper wiring
BACK
TAMPER (N.C)
ProSYS
Short
AUX
RED
Cover Tamper Only
+ - SET/
UNSET
LEDs
ENABLE
AM
YEL
FREE ALARM
TAMPER
GREEN
FREE
DUST TEST
COM
BLK
BUS
GRN YEL
BUS Mode:
Cover Tamper Wiring
ProSYS
Short
AUX
RED
Cover Tamper to Zone Input
+ - SET/
UNSET
LEDs
ENABLE
AM
YEL
FREE ALARM
TAMPER
GREEN
FREE
DUST TEST
COM
BLK
BUS
GRN YEL
BUS Mode:
Cover Tamper to Zone Input
ProSYS
BUS
Short
Zone
COM Z1 Z2
Zone
Input
AUX
RED
DIP Switch Settings
DIP Switch
Number Description
1 - 5 Used to set the detector ID number. Set the ID number in the same way as for
any other ProSYS accessory (Refer to the ProSYS installation instruction
manual)
6 - 8 Not used
