Management Station Statistics 3-15
Token Ring Statistics
• Click on the Total radio button. The window will now display the total count
of protocol types processed since the most recent start-up of the
MicroMMAC-T. The dynamic bar graph or pie chart to the right of the
numbers reflects counts processed since the last start-up.
Using the Pie and Bar Radio Buttons
You can use the Pie and Bar radio buttons to switch from bar graph to pie chart.
With the pie chart or bar graph, you can view the traffic, broken into protocols,
that is passing through the MicroMMAC-T. Both graphs will reflect the type of
collection you have chosen: Total or Delta.
To display a pie chart or bar graph:
1. Click on the Pie or Bar radio button. The Pie chart or the Bar graph, as you
have selected, will appear on the window.
Management Station Statistics
Through the Device menu, you can view network statistics for the
MicroMMAC-T’s on board ring management station.
Accessing the Management Station Statistics Selection
To access the Intelligent Module pull-down menu from the MicroMMAC-T
Chassis View window:
1. Click on the Device menu selection on the menu bar in the MicroMMAC-T
Chassis View. The Device menu will appear.
2. Click to highlight the Mgmt. Station Statistics... selection. The TR
Management Station Statistics window will appear.
The upper left corner of the The TR Management Station Statistics window
(
Figure 3-10 ) contains the module’s name, location, and MAC and IP addresses.
The window also lists the current ring speed set at the device.
