Managing the Hub 2-27
The MicroMMAC-T Chassis View
Setting the UPS ID
You need to set the UPS ID typecode that indicates the manufacturer and model
of the UPS.
To set the UPS ID:
1. Click on the arrow next to the SET UPS ID text box. A Model number menu
will appear. Scroll to highlight the appropriate UPS ID. (Consult the manual
that was included when you purchased your UPS for the correct Model ID
number.)
2. Click on OK. The UPS ID you have chosen will appear in the text box, and the
UPS window will be active.
If your UPS unit does not function after you have set this ID, check the manual
you received with the UPS to ensure that you have chosen the correct UPS ID. If
you need to change the ID, follow the directions given above.
Using the Test Option
You can use the test option to activate a self-test cycle for your unit. This self-test
will check the viability of your unit and its battery.
To activate the test:
1. Click on the Test button. The unit will begin its self-test. The results of the test
will appear in the Test Result text box next to the Test button.
Using the Disconnect Option
You can disconnect the UPS attached to your MicroMMAC-T through its COM
port, as follows:
1. Click on the Disconnect button near the bottom of the UPS window. Your
UPS will now be disconnected.
To reconnect, simply click on OK, or else close, and then re-open the UPS
window.
Resetting the Device
You can use the Restart Device selection to perform a software reset of the
MicroMMAC-T. To reset the device:
1. Click on the Network menu selection on the menu bar at the top of the
Chassis View window. The Network pull-down menu will appear.
2. Click on Restart Device.
