Software Conventions

1-5

Introduction

Using Window Buttons

The

button that appears at the bottom of most windows allows you to

exit a window and terminate any unsaved changes you have made. You may also
have to use this button to close a window after you have made any necessary
changes and set them by clicking on an

,

, or

button.

An

,

, or

button appears in windows that have

configurable values; it allows you to confirm and SET changes you have made to
those values. In some windows, you may have to use this button to confirm each
individual set; in other windows, you can set several values at once and confirm
the sets with one click on the button.

The

button brings up a Help text box with information specific to the

current window. For more information concerning Help buttons, see Getting
Help

,

page 1-7

.

The command buttons, for example

, call up a menu listing the windows,

screens, or commands available for that topic.

Any menu topic followed by ... (three dots) — for example Statistics... — calls up
a window or screen associated with that topic.

Common MicroMMAC-T Window Fields

Similar descriptive information is displayed in boxes at the top of most
device-specific windows in NetSight Element Manager, as illustrated in

Figure 1-2

.
