Managing the Hub 2-25
The MicroMMAC-T Chassis View
Accessing the UPS Window
At the UPS window, you can configure the UPS ID model type for the
uninterruptable power supply you have attached to the appropriate port on your
MicroMMAC-T.
You can also view information concerning the UPS connected to your
MicroMMAC-T including:
• The amount of time that your UPS has been running since the last start-up
• The line voltage and battery output
• The actual battery capacity of the UPS (dynamic bar graph)
You can also use a button at the bottom of the window to disconnect your UPS, or
you can use the Test option to initiate a self test of the unit.
To access the UPS window:
1. From the MicroMMAC-T Chassis View window, click on Device in the menu
bar to access the Device menu.
2. Drag down to UPS..., and release. The UPS window, Figure 2-14 , will appear.
Figure 2-14. The UPS Window
