Viewing Chassis Information 2-11
The MicroMMAC-T Chassis View
Port Assignment
You can view two Port Assignment categories for your ports:
• If you select FNB View, the port text boxes will display their current FNB
connection status. For single-ring devices like the MicroMMAC-T, the only
possible status condition is FNB 1.
• If you select Ring View, the port text boxes will display their current network
association status. The status conditions are: R1 (ring 1) and ORPH (orphan).
Ring Port Status
For the Ring-In/Out ports, two status conditions are possible:
• Active ( ), when the port is active and passing data.
• Wrapped ( ), when there has been a termination of data communications at
the port, and data has been rerouted to the backup path.
Port Status Color Codes
The port display options incorporate the following color-coding scheme:
• For the Status display options (Admin/Link or Admin) - green = INS/ON,
yellow = ENB, red = BYP/LNK/OFF, and blue = N/A (not available).
• For the Port Assignment display options - magenta = FNB/R 1, and gray =
ORPH.
For the Errors Port Status selection, color codes will continue to reflect the most
recently selected mode which incorporates its own color coding scheme.
NOTE
In NetSight Element Manager, the polling interval is set via the Tools—>Options
window available from the primary window menu bar.
Refer to the NetSight Element Manager User’s Guide for full information on setting
device polling intervals.
