The MicroMMAC-T Chassis View
2-8 Viewing Chassis Information
The Help Menu
The Help Menu has three selections:
• MIBS Supported , which brings up the Chassis Manager window. See The
Chassis Manager Window , page 2-12 .
• Chassis Manager Help , which brings up a help window with information
specifically related to using the Chassis Manager and Chassis View windows.
• About Chassis Manager... , which displays version information for the Chassis
Manager application in use.
The Module Menus
Module menus for each module in the MicroMMAC-T controlled stack displayed
in the Chassis View window provide the following selections:
• Status... , which updates you on the condition of a selected module. See
Viewing Module Status , page 2-20 , for details.
• Module Type... , which brings up a window containing a description of the
selected module; see Viewing Hardware Types , page 2-12 .
• Enable/Disable Station Ports , which allow you to enable or disable all station
ports on the selected module; see Enabling and Disabling Ports , page 2-31 .
• Enable/Disable Ring Ports , which allow you to enable or disable all ring ports
on the selected module. These selections will only appear in the Module menu
for modules which have ring-in/out ports. See
Enabling and Disabling Ports ,
page 2-31 , for details.
• Enable/Disable Link Traps , which allow you to enable or disable link traps for
all ports on the selected board. See Enabling and Disabling Link
Traps , page 2-29 .
• Set Board to Automode , which allows you to quickly configure a module in
the MicroMMAC-T controlled stack to operate according to its default settings.
See
Setting Token Ring Boards to Automode , page 2-30 , for details.
The Port Menus
The Port menu selections vary according to the port’s status. The menu for station
ports with an inserted station includes the following selections:
• Statistics... , which brings up the Station Statistics window showing
performance and error statistics for the selected port. See Chapter 3,
Token Ring Statistics
, for details.
• Timer Statistics... , which invokes the Station Timer Statistics window. See
Chapter 3 for details.
• Alarm Limits... , which launches the station-level alarms window; see
Chapter 4, Token Ring Alarms, for alarm configuration information.
• Performance Graph... , which brings up the Station Port Performance Graph.
See Chapter 3 for details.
