Token Ring Statistics
3-4 Network Level Statistics
4. Click on OK. The new Time Interval will take effect for the current instance of
the window in which you have set it. Remember, the poll interval returns to its
default value each time you close, and then re-open a statistics window.
Network Level Statistics
Using the Network pull-down menu, you can view performance statistics for the
MicroMMAC-T-managed ring. The MicroMMAC-T-managed ring is represented
by the Network 1 entry in the Network pull-down menu.
Windows which allow you to view performance information for a ring include:
• Statistics
• Timer Statistics
• Performance Graphs
• Frame Size
• Protocol
Accessing the Network Statistics Selections
To access the Network Statistics selections:
1. At the MicroMMAC-T Chassis View window, click on the Network menu
selection, then on the Network 1 entry to access the following statistics
selections:
• Statistics...
• Timer Statistics...
• Performance Graph...
• Frame Size...
• Protocol...
2. Highlight your selection. Each selection has an associated window.
The Network Statistics Window
At the Network Statistics window ( Figure 3-4 ), you can view Ring Status,
Beaconing, and Error fields for a MicroMMAC-T-managed ring.
General Information Fields
There are two general information fields in the Network Statistics Window:
Ring Number
This field displays the number provided by the Ring Parameter Server that is
used to identify the current ring. Possible values are 0001-0FFF (hexadecimal).
