The MicroMMAC-T Chassis View
2-6 Viewing Chassis Information
• Edit Device Time... and Edit Device Date..., which allow you to set the
MicroMMAC-T’s internal clock. See Setting the Device Date and Time ,
page 2-23 , for details
• System Group... , which allows you to manage the MicroMMAC-T via SNMP
MIB II. Refer to the Generic SNMP User’s Guide for further information.
• I/F Summary , which lets you view statistics for the traffic processed by each
SNMP MIB II interface on your device. See Viewing I/F Summary
Information , page 2-32 , for details.
• UPS... , which brings up a window that allows you to configure an
Uninterruptable Power Supply attached to your MicroMMAC-T; see Using an
Uninterruptable Power Supply (UPS) , page 2-24 , for details.
• Mgmt. Station Statistics... , allows you to view network statistics for the
MicroMMAC-T’s on board ring management station. See Chapter 3, Token
Ring Statistics
, for details.
• Configuration... , allows you to configure the ring management station,
including setting a device name and location, setting the error report timer
delay, enabling or disabling the automatic beacon recovery process (ABRP),
and inhibiting the active monitor. You can set up a ring management station
configuration for each MicroMMAC-T-managed ring network. See
Management Station Configuration , page 2-14 , for details.
• Exit , which closes the MicroMMAC-T Chassis View window.
The Port Status Menu
The Port Status menu allows you to select the status information that will be
displayed in the port text boxes in the logical Chassis View window:
• Load will display the portion of network load processed by each port as a
percentage of the theoretical maximum load (4 or 16 Mbits/sec) of a Token
Ring network.
• Status allows you to select one of two status type displays: Admin/Link or
Admin.
• Errors allows you to display the percentage per port of the specific Error you
select.
• Port Assignment displays either the current FNB connection status or the
Network association of each port.
For more information on the port display options available via this menu, see
Selecting a Port Status View , page 2-9 .
